12 Volt 200AH Deep Cycle AGM Battery V3957
Sale price
$29.90
Regular price $97.49
Skip to product information
Maintenance Free: Manufactured with thick absorbent glass mat (AGM) separators and advanced valve regulated technology, Renogy Deep Cycle AGM Batteries save you from acid leakage and frequent maintenance.
Excellent Discharge Performance: Proprietary quinary alloy plates and specially treated plate grids enable low internal resistance and high discharge currents of up to 10 times the battery rated capacity.
Long Shelf Life: Made of high purity materials, Renogy Deep Cycle AGM Batteries reduce the monthly self-discharge rate below 3% at 77℉ (25℃), which is 5 times lower than their flooded counterparts .
Wide Operation Temperature Range: Improved electrolyte formula ensures stable battery capacity and outstanding discharge performance at low temperatures below 32℉ (0℃).
Length of Cycle services is significantly affected by depth for discharge (primarily), along with ambient temperature, discharge Rate, and the way the battery is recharged.
NOTE: We highly recommend installing the battery upright. It is allowed to install the battery on its side only if there are special reasons for doing so. DO NOT install the battery upside down.
Size:200Ah | Style:Battery
12 Volt 200AH Deep Cycle AGM Battery V3957
Sale price
$29.90
Regular price $97.49
Shipping calculated at checkout.
Maintenance Free: Manufactured with thick absorbent glass mat (AGM) separators and advanced valve regulated technology, Renogy Deep Cycle AGM Batteries save you from acid leakage and frequent maintenance.
Excellent Discharge Performance: Proprietary quinary alloy plates and specially treated plate grids enable low internal resistance and high discharge currents of up to 10 times the battery rated capacity.
Long Shelf Life: Made of high purity materials, Renogy Deep Cycle AGM Batteries reduce the monthly self-discharge rate below 3% at 77℉ (25℃), which is 5 times lower than their flooded counterparts .
Wide Operation Temperature Range: Improved electrolyte formula ensures stable battery capacity and outstanding discharge performance at low temperatures below 32℉ (0℃).
Length of Cycle services is significantly affected by depth for discharge (primarily), along with ambient temperature, discharge Rate, and the way the battery is recharged.
NOTE: We highly recommend installing the battery upright. It is allowed to install the battery on its side only if there are special reasons for doing so. DO NOT install the battery upside down.
Size:200Ah | Style:Battery
| 100AH AGM Battery | 200AH AGM Battery | 100Ah GEL Battery | 200Ah GEL Battery | 100Ah Smart Lithium-Iron Phosphate | 170Ah Lithium-Iron Phosphate | |
|---|---|---|---|---|---|---|
| Nominal Voltage | 12V | 12V | 12V | 12V | 12V | 12V |
| Maximum Continuous Charging Current | 30A | 60A | 30A | 60A | 50A | 85A |
| Operating Temperature Range | Discharge: 5℉~122℉; Charge: 5℉~104℉ | Discharge: -4℉~140℉ ; Charge: 32℉~122℉ | Discharge: -4℉~140℉ ; Charge: 32℉~122℉ | Discharge: -4℉~140℉ ; Charge: 32℉~122℉ | Discharge: -4℉~140°F ; Charge: 32℉~131°F | Discharge: -4℉~140°F ; Charge: 32℉~113°F |
| Storage Temperature | 5℉~104℉ | -4℉~140℉ | -4℉~140℉ | -4℉~140℉ | -13℉~149℉ | 32℉~77℉ |
| Terminal | M8 | M8 | M8 | M8 | M8 | M12 |
| Connection Method | Parallel+Series | Parallel+Series | Parallel+Series | Parallel+Series | Parallel | Parallel |
| Communication Port | - | - | - | - | RJ45 (RS485 Protocol) | - |
| Weight | 63.9 lbs | 127.9lbs | 63.9 lbs | 127.9 lbs | 26 lbs | 48.5 lbs |
| Dimension | 13.1 x 6.9 x 8.6 inch | 20.6 x 9.4 x 8.8 inch | 12.9 x 6.8 x 8.7 inch | 20.6 x 9.4 x 8.8 inch | 11.4 x 6.8 x 7.4 inch | 13.7 x 6.1 x 10.6 inch |
| Shelf Mode | - | - | - | - | - |
